Smartscope quest 250
Smartscope quest 250




  1. #SMARTSCOPE QUEST 250 FULL#
  2. #SMARTSCOPE QUEST 250 PRO#
  3. #SMARTSCOPE QUEST 250 PLUS#
  4. #SMARTSCOPE QUEST 250 ZIP#

The 0.05 µm XYZ scales and dual X-axis scales are standard, for high-resolution positioning. Advanced sensor capability is available for specialized measurements, including optional touch probe, off-axis DRS or TeleStar Probe laser, on-axis TTL laser, off-axis Rainbow Probe scanning white light sensor, micro-measuring Feather Probe and SP25 scanning probe.

#SMARTSCOPE QUEST 250 ZIP#

ZIP Advance 250 provides a sharp video image, due to its AccuCentric auto-calibrating Zoom 70 lens, high-resolution digital metrology camera and three light sources.

  • SmartScope ZIP Advance 250 high performance benchtop dimensional measuring system with advanced sensor capability.
  • #SMARTSCOPE QUEST 250 PRO#

    Quest 300 may be preloaded with ZONE3 or ZONE3 Pro 3D CAD-based metrology software or with MeasureMind 3D MultiSensor. Multisensor versatility is a given with Quest, with optional touch probe, TTL interferometric laser, micro-probes and SP25 continuous contact scanning probe. Quest 300 provides accurate video metrology with its patented TeleStar telecentric 10:1 zoom optics for the highest level of optical performance.

    smartscope quest 250

  • SmartScope Quest 300 advanced-technology large-measurement-volume dimensional measuring system that fits on a benchtop.
  • #SMARTSCOPE QUEST 250 FULL#

    Multiple sensors may be deployed rotationally so full stage travel is measurement-accessible. High Mag allows up-close measurement of small features. With AutoID, previously programmed parts may be placed anywhere on the stage, and Fusion will identify them and their orientation and automatically measure them. AutoMeasure analyzes any part and displays its geometry without a programmed measurement routine. Low Mag makes it easy to fit multiple parts into a single 100 mm field-of-view. Fusion optics provide two magnifications.

    smartscope quest 250

  • Fusion 400 large-field-of-view multisensor measurement system that offers automated measurement and maximized throughput.
  • OGP will exhibit several state-of-the-art precision metrology systems and technologies including the following: The QVI divisions' latest precision dimensional measurement machines and software will be available for attendee demonstrations. ZONE3 represents the state-of-the-art in 3D metrology software.Quality Vision International (QVI), a vision metrology company, will exhibit a wide variety of advanced metrology solutions at EASTEC 2017. ZONE3 supports simultaneous use of multiple sensors, including multiple lasers, making appropriate tools available for complex measurement tasks. Built-in productivity maximizing tools, integrated GD&T functionality, and visual validation of measurement intent offer speed and power to the measurement process. ZONE3 features a clear, simple user interface, and its kinematic model simulates the machine, part, fixtures, and measuring sensor, updated in real time. SmartScope Quest 800 is available with QVI’s ZONE3® premium CAD-based 3D metrology software.

    #SMARTSCOPE QUEST 250 PLUS#

    SmartScope Quest 800 is fully multisensor-capable with available touch trigger probe, SP25 continuous contact scanning probe with PH10 motorized probe head, patented on-axis TeleStar Plus interferometric TTL laser or off-axis DRS™ laser, and micro-probes to measure fragile parts or extremely small part features. The innovative 10:1 TeleStar® telecentric zoom lens provides high-level optical performance and accurate video metrology.

    smartscope quest 250

    For measurement stability, the Quest 800 optics/sensor head is mounted on a stable granite bridge over the worktable and moves only in the X and Z axes, while the worktable itself moves underneath in the Y axis. With its generous 790x815x250 mm XYZ measurement volume and available 300 or 400 mm extended Z axis, SmartScope Quest 800 accurately measures very large parts or large arrays of smaller fixtured parts. Optical Gaging Products (OGP®), a division of Quality Vision International (QVI®), now offers its large measurement volume SmartScope® Quest 800 multisensor dimensional measurement system to the metrology marketplace.






    Smartscope quest 250
